MTA:SA Fireworks

This resource exposes two functions via the export system. Call them from any other resource using exports.firework:functionName(...).

---

createRocket

Spawns a firework rocket at a given position. The rocket flies upward and triggers an explosion once it reaches the target height.

Syntax

table createRocket ( float x, float y, float z, [ float targetHeight, string type, table primaryColor, table secondaryColor, float duration, float size ] )

exports.firework:createRocket ( float x, float y, float z, [ float targetHeight, string type, table primaryColor, table secondaryColor, float duration, float size ] )

Required Arguments

• x: The X world coordinate for the rocket's start position.
• y: The Y world coordinate for the rocket's start position.
• z: The Z world coordinate for the rocket's start position.

Optional Arguments

• targetHeight: Height in units relative to z at which the explosion triggers. Default: 80.
• type: The explosion shape to use. See Firework Types for all available values. Default: "sphere".
• primaryColor: Main color as an RGB table, e.g. {255, 0, 0}. Values range from 0 to 255 or 0.0 to 1.0. If omitted, a random palette is chosen.
• secondaryColor: Secondary color for two-tone effects. Same format as primaryColor. Defaults to primaryColor if omitted.
• duration: Flight duration in seconds. Defaults to the resource's internal config value.
• size: Size multiplier for the explosion. Default: 1.0.

Example

-- Launch a red heart-shaped rocket at the local player's position
local x, y, z = getElementPosition(localPlayer)
exports.firework:createRocket({
    x = x, y = y, z = z,
    targetHeight = 100,
    type = "heart",
    primaryColor   = {255, 0, 0}, -- or {1, 0, 0}
    secondaryColor = {255, 255, 0}, -- or {1, 1, 0}
    size = 1.2
})

---

createFirework

Triggers a firework explosion directly at a given position without any rocket flight.

Syntax

exports.firework:createFirework ( float x, float y, float z, [ string type, table primaryColor, table secondaryColor, int numRays, float speed, float gravity, float duration, float size ] )

Required Arguments

• x: The X world coordinate of the explosion.
• y: The Y world coordinate of the explosion.
• z: The Z world coordinate of the explosion.

Optional Arguments

• type: The explosion shape to use. See Firework Types for all available values. Default: "sphere".
• primaryColor: Main color as an RGB table, e.g. {51, 153, 255}. Values range from 0 to 255 or 0.0 to 1.0. If omitted, a random palette is chosen.
• secondaryColor: Secondary color for two-tone effects. Defaults to primaryColor if omitted.
• numRays: Number of rays or particles emitted. Defaults to the type's built-in value.
• speed: Expansion speed of the explosion. Defaults to the type's built-in value.
• gravity: Gravitational pull applied to particles. Defaults to the type's built-in value.
• duration: Display duration in seconds. Defaults to the type's built-in value.
• size: Size multiplier for the explosion. Default: 1.0.

Example

-- Trigger a blue chrysanthemum burst at a fixed world position
exports.firework:createFirework({
    x = 500, y = 500, z = 120,
    type = "chrysanthemum",
    primaryColor = {51, 153, 255},
    size = 1.5
})

---

Firework Types

The type parameter accepts the following string values:

Classic shapes

• sphere
• chrysanthemum
• willow
• palm
• ring
• dahlia
• crossette
• kamuro
• peony
• spider
• comet
• brocade
• strobe
• double

Special shapes

• heart
• star
• maltese
• cruciform
• avengers

Algebraic curves

These types are rendered using classical mathematical curve equations. See mathworld.wolfram.com for formula references.

• astroid
• lemniscate
• cardioid
• butterfly
• rose
• trifolium
• quadrifolium
• spirograph
• deltoid
• nephroid
• epicycloid
• hypocycloid
• lissajous
• eight
• spiral
